This could be a motion sensor, maglock, or Kisi. From the NC port on your REX, connect to the COM of the next hardware component in the circuit. From the COM port on the REX, connect to the positive lead of your power supply. If you are wiring a Fail-Safe lock, you must maintain a closed (Series) circuit to continuously power your lock. Swap the wires on the button’s terminals and plug in the button again to test.Ĭonnect the circuit signal wires to Common (COM) and Normally Closed (NC) If the button does not light up, you may have to observe the polarity of the LED.
When you plug the power supply in, you should see the LED light of the button turn on. The easiest connection order is as follows:Ĭonnect and power the LED on your REX buttonĬonnect + and - on the REX button to power the LED light using a 12/24V power supply. If you are not completely familiar with installing REX buttons, Kisi highly recommends that you make your connections one pair at a time. Note: + and - can sometimes be labeled as LED+ and LED- but are essentially the same. Two wires (+, -) will power the LED on the button, and two wires ( C-NC or C-NO) will serve as signal wires that connect to the rest of your installation components (lock, Kisi, other ancillary parts). The typical REX button has 5 wires, (+, -, COM, NO, NC), although only 4 are needed for normal operation.
How are you connecting your REX button with the rest of your circuit? If you are in a situation where you do not have a power supply on hand and need to power a small amount of ancillary components, you can elect to use the power outputs located on the Kisi Controller. As a reminder, if you pull more than 4A through the Kisi Controller, the board will short circuit and become useless. An external power supply is more likely to provide the amperage you need to power those components. Kisi recommends that you always power your ancillary components based off of an external power supply.
#Push to exit button city of allen pro
The main options we will discuss are 1) External Power Supply and 2) Kisi Pro Controller’s power outputs. You may have a few options for a power source during your installation. Here are the questions you should ask when installing a REX button:
#Push to exit button city of allen install
There should be no need to install a REX for Fail-Secure locks because you should always have free egress via lockset. Note: A REX button is primarily used in Kisi-standalone installations on a Fail-Safe lock. Here is a quick video of how push to exit buttons work: There are also panic exit devices such as push to exit bars. Motion sensors to trigger the door to unlock Regular wall-mount push to exit buttonsĢ. Push to exit buttons mainly come in two types:ġ. The lock will disengage, thus, opening the door as required. With this, the door automatically releases and allows free exit. The exit button releases power to the magnetic lock. When pushed, it momentarily releases the fail-secure or fail-safe lock of the door. Any individual that needs to exit the building or pass through the door simply has to push or press the button. The push to exit button is connected to the access control application, which controls the locking mechanism of the door, using wires. However, the button must be able to hold enough power for the door to open freely. It can be used when the door’s handle isn’t suitable, or the user is not able to use the handle physically. In some cases, the push to exit buttons can be used when the access control panel fails to unlock the door. It can be used as exit devices in residential, commercial, and industrial buildings. The exit push button can be used on fire doors, gates, or anywhere you can install an access control system. Exit buttons are suitable for use in electronic locking solution which needs to provide a free exit option on the door. One of the advantages of the push to exit button is the versatility it offers. When Should a Push to Exit Button Be Installed? The exit push button is used to “request to exit” devices in the access control system that are used on doors, exits, gates, automation control, and so forth. It can be a simple or large button, green, or button that illuminate LED lights. It is a spring-loaded, button which is often mounted on a stainless steel plate.
Push to exit buttons are an essential part of access control applications. The push to exit button is often the item of choice. Only a simple device will be needed to unlock the door. However, exiting the building does not require any sophisticated equipment.
At the same time, someone inside the building will want to exit. This ensures that only authorized individuals are granted access to the building. To do this, access control systems are installed on doors, exits, and gates. Today, businesses often implement security measures to stop unauthorized personnel from getting into a building or restricted area.
